HD Lateral Packer
Straightforward Repairs in Lateral Pipes
The HD Lateral Packer is a robust and versatile tool for trenchless point repairs in lateral pipe sections ranging from DN 70 to DN 200. Built with reinforced materials and optimised for quick inflation and deflation, it enables fast, secure repairs without the need for excavation.
Key Features:
- Suitable for DN 70–200
- Ideal for lateral and branch line rehabilitation
- Durable, reinforced rubber body
- Compact and easy to deploy
- Supports efficient, trenchless repairs
DN 25 – 1000
Up to 5 dimensions
Up to 45°
Sizes: 25-60 | 30-100 | 50-150 | 70-200 | 100-250 | 125-300 | 200-500 | 300-1000
For short liner and house connection rehabilitation, HD developed their multidimensional lateral packer. The sewer rehabilitation packers are high-quality and durable and enable unique pipe dimension jumps. For example the HD lateral DN 125-300 packer is able to inflate into 5 pipe dimensions – that´s unique!
Advantages
- Small packer diameter f. e. DN 70-200
- Unique dimension
- Dimensionally stable and nevertheless high-flexible
- Customization on customer ́s specifications
- Ideal push performance
- with three HD packer you can reach nominal diameter of DN 30-1000
- Efficient and economical working
- Can be upgraded with flex adapter
- With pre-fitting for steam curing
